BOMBTRACK TENSION TWO

SPECIFICATIONS

Color 1	Glossy Grey / Green
Color 2	-
Frame	6061-T6 double-butted aluminum, TA, rack/fender mounts, 86.5 mm BB T47 shell
Fork	full carbon, TA, 1.1/2'' - 1.1/8'', fender mounts
Handlebar	RITCHEY ROAD COMP STREAM III drop bar, 31.8 mm, 5° backsweep
Grips	BOMBTRACK COMMAND bar tape
Stem	RITCHEY COMP 4-AXIS 44 aluminum stem, -6°
Headset	Sealed integrated headset, 1.1/2'' - 1.1/8''
Levers	SRAM RIVAL 1 double tap hydraulic
Shifter	SRAM RIVAL 1 double tap 1 x 11
Brakes	SRAM RIVAL flat mount hydraulic disc brakes with 140 mm rotors
Crankset	BOMBTRACK LYER forged aluminum crank, direct mount interface (SRAM compatible),30 mm spindle
BB	BOMBTRACK T47 internal sealed BB for 30 mm spindle
Pedals	-
Chain	KMC X11 EPT Anti Rust chain, 1/2'' x 11/128'', 114L
Chainring	CNC machined aluminum, narrow-wide, 40 T
Cassette	SRAM PG-1130 11-speed, 11 - 36 T
Front Derailleur	-
Rear Derailleur	SRAM RIVAL 1, clutch, long cage
Front hub	HUNT 4 SEASON V2 sealed hub, 6-bolt disc
Rear hub	HUNT 4 SEASON V2 sealed hub, 11-speed, 6-bolt disc
Through axle	12 x 100 mm / 12 x 142 mm
Front rim	HUNT 4 SEASON double wall asymmetric rim, TLC, i19, 24h
Rear rim	HUNT 4 SEASON double wall asymmetric rim, TLC, i19, 24h
Saddle	BOMBTRACK DART saddle
Seat post	RITCHEY COMP 2-BOLT aluminum seatpost 27.2 mm x 300 mm
Seat clamp	BOMBTRACK ORIGIN forged aluminum seat clamp, 31.8 mm
Front tire	XS - S VEE TIRE XCX 120 TPI TLR 32-584 / M - XL CHALLENGE GRIFO TLR 33-622, tubeless ready
Rear tire	XS - S VEE TIRE XCX 120 TPI TLR 32-584 / M - XL CHALLENGE GRIFO TLR 33-622, tubeless ready
Fender	-
Rack	-
Kickstand	-
Light	-
Weight	8.9 kg (size M)
Weight frameset	1580 g frame (size L, incl. TA, hanger) / 610 g fork (300 mm steerer, incl. TA)
Maximum rider weight	115 kg incl. luggage
ASTM riding condition	2

BUILD INFORMATION

BB standard	T47 - 86.5 mm shell width
Headset standard (S.H.I.S.)	IS42 / 28.6 \| IS52 / 40
Headset crown race angle	45°
Fork steerer inner diameter	23.6 mm
Fork max tire clearance w/o fender	XS - S 650B x 37C / M - XL 700C x 37C
Frame max tire clearance w/o fender	XS - S 650B x 35C / M - XL 700C x 37C
Maximum chainring clearance 1x	42 T with 45 mm chainline
Maximum chainring clearance 2x	50 / 34 T with 43.5 mm chain line
Seat post diameter	27.2 mm
Seat clamp diameter	31.8 mm
Front derailleur clamp diameter	31.8 mm
Brake mount front	FM
Brake mount rear	FM
Maximum rotor clearance front	160 mm
Maximum rotor clearance rear	160 mm
Front through axle	12 mm x 100 mm, 1.5 thread pitch
Rear through axle	12 mm x 142 mm, 1.5 thread pitch
ISO testing standard	Road
Crankarm	XS - S 165 mm / M 170 mm / L - XL 175 mm
Q Factor	152 mm
BCD crank	Direct mount (Sram compatible)
Chainline	45 mm
Chainring offset	5 mm
Spoke length front wheel	XS - S 273 mm, 274 mm / M - XL 291 mm, 293 mm
Spoke length rear wheel	XS - S 274 mm, 272 mm / M - XL 293 mm, 291 mm
Spoke count (front / rear)	32 / 32
ERD	XS - S 570 mm / M - XL 604 mm
Front hub PCD	58 mm
Rear hub PCD	58 mm
Front hub flange distance/offset	56.5 mm center to center / 6.6 mm
Rear hub flange distance/offset	51 mm center to center / 8.8 mm
Stem length	XS - S 80 mm / M 90 mm / L - XL 100 mm
Stem angle	-7°
Headset spacers	1 x 10 mm, 2 x 5 mm
Seat post offset	24 mm
Seat post length	315 mm
Derailleur hanger	BT-DH-018
Frame small parts	BT-CR-013
Hub end caps front	BT-HC-012
Hub end caps rear	BT-HC-017
Cassette body	BT-CB-006
Crankarm bolt	BT-CRP-002
Through axle front	BT-TA-F-603
Through axle rear	BT-TA-R-601
