BOMBTRACK ARISE SINGLE SPEED

SPECIFICATIONS

Color 1	Glossy Coffee Black
Color 2	Glossy Metallic Pearl Blue
Frame	4130 double butted CrMo, heat-treated front triangle, TA sliding dropouts, rack/fender mounts, 68 mm BSA BB shell
Fork	4130 CrMo, TA, rack/fender mounts, internal hub dynamo cable routing
Handlebar	BOMBTRACK CX-10 drop bar, 31.8 mm, 10° flare
Grips	BOMBTRACK CONTROL bar tape
Stem	BOMBTRACK ROAM forged aluminum stem, -7°
Headset	NECO H282 sealed external headset, 1.1/8''
Levers	TEKTRO RL-340 brake levers
Shifter	-
Brakes	TEKTRO MIRA post mount mechanic disc brakes with 160 mm rotors
Crankset	BOMBTRACK TAF19 aluminum crank, 24 mm spindle
BB	BSA sealed BB, external cups
Pedals	WELLGO B109N flat pedal
Chain	KMC X8 chain, 1/2'' x 3/32'', 98L
Chainring	BOMBTRACK RIDGE aluminum chainring, narrow-wide, 42 T
Cassette	16 T heat-treated CrMo, 1/2'' x 3/32''
Front Derailleur	-
Rear Derailleur	-
Front hub	BOMBTRACK ARC sealed hub, 6-bolt disc
Rear hub	BOMBTRACK ARC sealed hub, 11-speed, 6-bolt disc
Through axle	12 x 100 mm / 12 x 142 mm
Front rim	WTB ST i19 double wall, TCS 2.0, 32h
Rear rim	WTB ST i19 double wall, TCS 2.0, 32h
Saddle	BOMBTRACK FUZZ
Seat post	BOMBTRACK BEECH 27.2 mm x 315 mm
Seat clamp	BOMBTRACK ORIGIN 29.8 mm
Front tire	XS - S VEE TIRE SPEEDSTER 38-584 / M - XL VEE TIRE SPEEDSTER 40-622
Rear tire	XS - S VEE TIRE SPEEDSTER 38-584 / M - XL VEE TIRE SPEEDSTER 40-622
Fender	-
Rack	-
Kickstand	-
Light	-
Weight	11.4 kg (size M)
Weight frameset	2480 g frame (size M, incl. TA, hanger) / 1370 g fork (300 mm steerer, incl. TA)
Maximum rider weight	120 kg incl. luggage
ASTM riding condition	2

BUILD INFORMATION

BB standard	BSA - 68 mm shell width
Headset standard (S.H.I.S.)	EC34 / 28.6 \| EC34 / 30
Headset crown race angle	45°
Fork max tire clearance w/o fender	XS - S 650B x 42C / M - XL 700C x 42C
Frame max tire clearance w/o fender	XS - S 650B x 42C / M - XL 700C x 42C*
Maximum chainring clearance 1x	44 T with 45 mm chain line
Maximum chainring clearance 2x	52 / 36 T with 45 mm chain line
Seat post diameter	27.2 mm
Seat clamp diameter	29.8 mm
Brake mount front	PM
Brake mount rear	PM
Maximum rotor clearance front	160 mm
Maximum rotor clearance rear	160 mm
Front through axle	12 mm x 100 mm, 1.5 thread pitch
Rear through axle	12 mm x 142 mm, 1.5 thread pitch
Derailleur hanger	BT-DH-022
ISO testing standard	Road
Crankarm	XS 165 mm / S - M 170 mm / L - XL 175 mm
Q Factor	170 mm
BCD crank	130 mm, 5 bolts
Chainring Offset
Chainline	45 mm
Spoke length front wheel	XS - S 273 mm, 274 mm / M - XL 292 mm, 293 mm
Spoke length rear wheel	XS - S 272 mm, 274 mm / M - XL 291 mm, 293 mm
Spoke count (front/rear)	32 / 32
ERD	XS - S 570 mm / M - XL 604 mm
Front hub PCD	58 mm
Rear hub PCD	58 mm
Front hub flange distance/offset	56.5 mm center to center / 6.6 mm
Rear hub flange distance/offset	51 mm center to center / 8.8 mm
Stem length	XS - S 80 mm / M 90 mm / L - XL 100 mm
Stem angle	-6°
Headset spacers	1 x 10 mm, 2 x 5 mm
Seat post offset	24 mm
Seat post length	300 mm
