BOMBTRACK AUDAX AL BIKE

SPECIFICATIONS
Color 1   Glossy Sky Blue
Color 2   -
Frame   6061-T6 double-butted aluminum, TA, fender mounts, 86.5 mm T47 BB shell
Fork   Full carbon, TA, 1.1/2'' - 1.1/8'', with fender / cage mounts
Handlebar   BOMBTRACK CX-10 drop bar, 31.8 mm, 10° flare
Grips   BOMBTRACK COMMAND bar tape
Stem   BOMBTRACK ROAM forged aluminum stem, -7°
Headset   Sealed integrated headset, 1.1/2'' - 1.1/8''
Levers   MICROSHIFT SB-M110 DUAL CONTROL LEVER mechanic
Shifter   MICROSHIFT SB-M110 DUAL CONTROL LEVER 1 x 11
Brakes   TRP Spyre C flat-mount disc brakes with 160 mm rotors
Crankset   BOMBTRACK LYER forged aluminum crank, direct mount interface (SRAM compatible),30 mm spindle
BB   BOMBTRACK T47 internal sealed BB for 30 mm spindle
Pedals   -
Chain   KMC X11 chain, 1/2'' x 11/128'', 114L
Chainring   CNC machined aluminum, narrow-wide, 40 T
Cassette   MICROSHIFT CS-HG113 11-speed, 11 - 46 T
Front Derailleur   -
Rear derailleur   MICROSHIFT RD-M665M, clutch, medium cage
Front hub   BOMBTRACK ARC sealed hub, 6-bolt disc
Rear hub   BOMBTRACK ARC sealed hub, 11-speed, 6-bolt disc
Through axle   12 x 100 mm / 12 x 142 mm
Front rim   WTB ST i21 double wall, TCS 2.0, 32h
Rear rim   WTB ST i21 double wall, TCS 2.0, 32h
Saddle   BOMBTRACK DART saddle
Seat post   BOMBTRACK BEECH aluminum Seatpost, 27.2 mm x 415 mm
Seat clamp   BOMBTRACK ORIGIN forged-aluminum seat clamp, 31.8 mm
Front tire   WTB HORIZON 650B x 47C
Rear tire   WTB HORIZON 650B x 47C
Fender   -
Rack   -
Kickstand   -
Light   -
Weight   10.4 kg (size M)
Weight frameset   1810 g frame (size M, incl. TA, hanger) / 530 g fork (300 mm steerer, incl. TA)
Maximum rider weight   120 kg incl. luggage
ASTM riding condition   2
BUILD INFOS
BB standard   T47 - 86.5 mm shell width
Headset standard (S.H.I.S.)   IS42 / 28.6 | IS52 / 40
Headset crown race angle   36°
Fork steerer inner diameter   23.6 mm
Fork max tire clearance w/o fender   650B x 50C / 700C x 35C
Frame max tire clearance w/o fender   650B x 50C / 700C x 35C
Maximum chainring clearance 1x   42 T with 45 mm chainline
Maximum chainring clearance 2x   50 / 34 T with 43.5 mm chainline
Seat post diameter   27.2 mm
Seat clamp diameter   31.8 mm
Front derailleur clamp diameter   FD braze on
Brake mount front   FM
Brake mount rear   FM
Maximum rotor clearance front   160 mm
Maximum rotor clearance rear   160 mm
Front through axle   12 mm x 100 mm, 1.5 thread pitch
Rear through axle   12 mm x 142 mm, 1.5 thread pitch
ISO testing standard   Road
Crankarm   XS 165 mm / S - M 170 mm / L - XL 175 mm
Q Factor   152 mm
BCD crank   Direct mount (Sram compatible)
Chainline   45 mm
Chainring offset   5 mm
Spoke length front wheel   273 mm, 274 mm
Spoke length rear wheel   274 mm, 272 mm
Spoke count (front / rear)   32 / 32
ERD   568 mm
Front hub PCD   58 mm
Rear hub PCD   58 mm
Front hub flange distance / offset   56.5 mm center to center / 6.6 mm
Rear hub flange distance / offset   51 mm center to center / 8.8 mm
Stem length   XS - S 80 mm / M 90 mm / L - XL 100 mm
Stem angle   -7°
Headset spacers   1 x 10 mm, 2 x 5 mm
Seat post offset   24 mm
Seat post length   415 mm
Derailleur hanger   BT-DH-018
Frame small parts   BT-CR-013
Hub end caps front   BT-HC-012
Hub end caps rear   BT-HC-017
Cassette body   BT-CB-006
Crankarm bolt   BT-CRP-002
Through axle front   BT-TA-F-601
Through axle rear   BT-TA-R-601
