BOMBTRACK BEYOND 1

SPECIFICATION

Color 1	Glossy Metallic Black
Color 2	-
Frame	4130 double butted CrMo, TA, rack/fender mounts, internal light cable routing, 73 mm BSA BB shell
Fork	4130 CrMo, double-butted blades, TA, 1.1/2'' - 1.1/8'', fender / rack / triple cage mounts, internal hub dynamo cable routing
Handlebar	BOMBTRACK BEYOND travel bar, 31.8 mm, 30° flare
Grips	BOMBTRACK COMMAND bar tape
Stem	BOMBTRACK WANDER forged aluminum stem, +17°
Headset	Sealed external headset, 1.1/2'' - 1.1/8''
Levers	SRAM Apex double tap mechanic
Shifter	SRAM Apex double tap 2 x 10
Brakes	TRP SPYRE C mechanic disc brakes with 180 mm F / 160 mm R rotors
Crankset	BOMBTRACK AMES forged aluminum crank, 24 mm spindle
BB	BSA sealed BB, external cups
Pedals	-
Chain	KMC X10 chain, 1/2'' x 11/128'', 114L
Chainring	Aluminium / Steel, 40 / 28 T
Cassette	SRAM PG-1020 10-speed, 11 - 36 T
Front Derailleur	Microshift FD-M612-B
Rear Derailleur	SRAM GX, short cage
Front hub	BOMBTRACK GRAD sealed hub, 6-bolt disc
Rear hub	BOMBTRACK ARC sealed hub, 11-speed, 6-bolt disc
Through axle	15 x 100 mm / 12 x 142 mm
Front rim	WTB ST i23 double wall, TCS 2.0, 32h
Rear rim	WTB ST i23 double wall, TCS 2.0, 32h
Saddle	BOMBTRACK FUZZ
Seat post	BOMBTRACK BEECH 27.2 mm x 415 mm
Seat clamp	BOMBTRACK ORIGIN 29.8 mm
Front tire	WTB RANGER TCS LIGHT / FAST ROLLING XS - S 27.5'' x 2.0'' / M - XL 29'' x 2.0'', tubeless ready
Rear tire	WTB RANGER TCS LIGHT / FAST ROLLING XS - S 27.5'' x 2.0'' / M - XL 29'' x 2.0'', tubeless ready
Fender	-
Rack	-
Kickstand	-
Light	-
Weight	12.9 kg (size M)
Weight frameset	2540 g frame (size M, incl. TA, bolts, seat clamp, hanger) / 1500 g fork (300 mm steerer, incl. TA)
Maximum rider weight	140 kg incl. luggage
ASTM riding condition	2

BUILD INFORMATION

BB standard	BSA - 73 mm shell width
Headset standard (S.H.I.S.)	EC34 / 28.6 \| EC44 / 40
Headset crown race angle	45°
Fork steerer inner diameter	25.4 mm
Fork max tire clearance w/o fender	XS - S 27.5'' x 2.1'' / M - XL 29'' x 2.1''
Frame max tire clearance w/o fender	XS - S 27.5'' x 2.1'' / M - XL 29'' x 2.1''
Maximum chainring clearance 1x	36 T with 48 mm chain line
Maximum chainring clearance 2x	42 / 28 T with 49.5 mm chain line
Seat post diameter	27.2 mm
Seat clamp diameter	29.8 mm
Front derailleur clamp diameter	28.6 mm
Brake mount front	PM
Brake mount rear	FM
Maximum rotor clearance front	203 mm
Maximum rotor clearance rear	160 mm
Front through axle	15 mm x 100 mm, 1.5 thread pitch
Rear through axle	12 mm x 142 mm, 1.5 thread pitch
ISO testing standard	MTB
Crankarm	XS 165 mm / S - M 170 mm / L - XL 175 mm
Q Factor	179 mm
BCD crank	104 mm / 64 mm, 4 bolts
Chainline	49.5 mm
Chainring Offset	0 mm
Spoke length front wheel	XS - S 272mm, 273 mm / M - XL 292 mm, 293 mm
Spoke length rear wheel	XS - S 273mm, 272 mm / M - XL 293 mm, 291 mm
Spoke count (front / rear)	32 / 32
ERD	XS - S 570 mm / M - XL 606 mm
Front hub PCD	58 mm
Rear hub PCD	58 mm
Front hub flange distance/offset	56.5 mm center to center / 6.6 mm
Rear hub flange distance/offset	51 mm center to center / 8.8 mm
Stem length	XS - S 60 mm / M - L 80 mm / XL 90 mm
Stem angle	17°
Headset spacers	1 x 10 mm, 2 x 5 mm, XL: 1 x 10 mm, 1 x 5 mm
Seat post offset	24 mm
Seat post length	415 mm
Derailleur hanger	BT-DH-008
Frame small parts	BT-CR-007
Hub end caps front	BT-HC-015
Hub end caps rear	BT-HC-017
Cassette body	BT-CB-006
Crankarm bolt	BT-CRP-001
Through axle front	BT-TA-F-602
Through axle rear	BT-TA-R-602
