BOMBTRACK HOOK

SPECIFICATIONS

Color 1	Glossy Metallic Black / Purple
Color 2	Glossy Metallic Blue
Frame	COLUMBUS CROMOR double-butted, TA dropout, rack/fender mounts, 86.5 mm T47 BB shell
Fork	Full carbon, TA, 1.1/2'' - 1.1/8'', fender / triple cage mounts
Handlebar	BOMBTRACK CX-10 drop bar, 31.8 mm, 10° flare
Grips	BOMBTRACK COMMAND bar tape
Stem	BOMBTRACK ROAM forged aluminum stem, -7°
Headset	Sealed external headset, 1.1/2'' - 1.1/8''
Levers	SHIMANO GRX ST-RX400 STI Hydraulic
Shifter	SHIMANO GRX ST-RX400 STI 2 x 10
Brakes	SHIMANO GRX BR-RX400 hydraulic disc brakes with 160 mm rotors
Crankset	BOMBTRACK LYER forged aluminum crank, direct mount interface (SRAM compatible),30 mm spindle
BB	BOMBTRACK T47 internal sealed BB for 30 mm spindle
Pedals	-
Chain	KMC X10 EPT Anti Rust chain, 1/2'' x 11/128'', XS - S 112L, M - XL 114L
Chainring	Aluminum, subcompact, 48 / 32 T, direct mount spider
Cassette	SHIMANO CS-HG50 10-speed, 11 - 36 T
Front Derailleur	SHIMANO GRX FD-RX400
Rear Derailleur	SHIMANO GRX RD-RX400, clutch
Front hub	BOMBTRACK TAU sealed hub, 6-bolt disc
Rear hub	BOMBTRACK TAU sealed hub, 11-speed, 6-bolt disc
Through axle	12 x 100 mm / 12 x 142 mm
Front rim	WTB ST i19 double wall, TCS 2.0, 32h
Rear rim	WTB ST i19 double wall, TCS 2.0, 32h
Saddle	Color 1 BOMBTRACK DART saddle / Color 2 BOMBTRACK COMP saddle
Seat post	BOMBTRACK BEECH 27.2 mm x 315 mm
Seat clamp	BOMBTRACK ORIGIN 29.8 mm
Front tire	XS - S WTB RESOLUTE 42-584 / M - XL WTB VENTURE 40-622, tubeless ready
Rear tire	XS - S WTB RESOLUTE 42-584 / M - XL WTB VENTURE 40-622, tubeless ready
Fender	-
Rack	-
Kickstand	-
Light	-
Weight	11.0 kg (size M)
Weight frameset	2420 g frame (size M, incl. TA, hanger) / 600 g fork (300 mm steerer, incl. TA)
Maximum rider weight	120 kg incl. luggage
ASTM riding condition	2

BUILD INFORMATION

BB standard	T47 - 86.5 mm shell width
Headset standard (S.H.I.S.)	EC34 / 28.6 \| EC44 / 40
Headset crown race angle	45°
Fork steerer inner diameter	23.6 mm
Fork max tire clearance w/o fender	XS - S 650B x 52C / M - XL 700C x 45C
Frame max tire clearance w/o fender	XS - S 650B x 42C / M - XL 700C x 42C
Maximum chainring clearance 1x	40 T with 45 mm chain line
Maximum chainring clearance 2x	48 / 32 T with 46.9 mm chain line
Seat post diameter	27.2 mm
Seat clamp diameter	29.8 mm
Front derailleur clamp diameter	28.6 mm
Brake mount front	FM
Brake mount rear	FM
Maximum rotor clearance front	160 mm
Maximum rotor clearance rear	160 mm
Front through axle	12 mm x 100 mm, 1.5 thread pitch
Rear through axle	12 mm x 142 mm, 1.5 thread pitch
ISO testing standard	Road
Crankarm	XS - S 165 mm / M 170 mm / L - XL 175 mm
Q Factor	152 mm
BCD crank	104 mm (Sram direct mount compatible spider),4 bolts
Chainline	45 mm
Chainring offset	small ring 0 mm / big ring -2 mm
Spoke length front wheel	XS - S 273, 275mm / M - XL 292 mm, 293 mm
Spoke length rear wheel	XS - S 275, 273mm / M - XL 293 mm, 291 mm
Spoke count (front / rear)	32 / 32
ERD	XS - S 570 mm / M - XL 604 mm
Front hub PCD	58 mm
Rear hub PCD	58 mm
Front hub flange distance/offset	56.5 mm center to center / 6.6 mm
Rear hub flange distance/offset	51 mm center to center / 8.8 mm
Stem length	XS - S 80 mm / M 90 mm / L - XL 100 mm
Stem angle	-7°
Headset spacers	1 x 10 mm, 2 x 5 mm
Seat post offset	24 mm
Seat post length	315 mm
Derailleur hanger	BT-DH-008
Frame small parts	BT-CR-007
Hub end caps front	BT-HC-014
Hub end caps rear	BT-HC-017
Cassette body	BT-CB-006
Crankarm bolt	BT-CRP-002
Through axle front	BT-TA-F-601
Through axle rear	BT-TA-R-602
